TV iTMDS Transmitter
Add High Bandwidth Content Protection (HDCP) to WUXGA and WQXGA resolution displays with Lattice dual-link iTMDS transmitter ICs.
The ideal internal panel interconnect – Using iTMDS technology, the dual-link transmitter can support High Bandwidth Content Protection (HDCP).
High resolution – Display resolutions up to WUXGA in single-link mode and up to WQXGA resolution in dual-link mode are supported.
Reduced system EMI levels – Able to operate at high levels of spread spectrum clocking, the SiI7172 significantly reduces system EMI levels at high operating frequencies.
Features
Fully TMDS/iTMDS compliant and fully interoperable in the DVI 1.0 environment
Scalable bandwidth: 25-225 MHz (VGA to WUXGA) standard pixel rate input, with high color depth support up to 225 MHz link clock frequency
Long cable support: the DVI cable can be over 20 meters long
Advanced on-chip input clock jitter filter to ensure clean output to receiver
Supports Dual-Link iTMDS interface for increased bandwidth
Do you know more about Lattice's product uses, technical documents, and solutions related to TV iTMDS Transmitter? Then quickly get in touch with Lattice Distributor - NHE!
